Construction Grade Bentonite

Bentonite for Construction Industry

As the main supplier to mega construction projects in the world, ANEDM is the leader in the field of construction bentonite products. Thanks to its pure, homogeneous and natural structure, our construction bentonite provides efficient and precise solutions for long life structures, sealing pads and impermeable wall constructions, impermeable building wall constructions and load-resistant building walls, fore pile applications, TBMs, injection processes.

Relevance

Advantages we provide:

  • When ANEDM Construction Bentonite is involved in cement grout or mortar, during the mixing and injection, the cement particles and sand are held in suspension to ensure that the mortar is stable. It minimizes the decomposition of water in cement water mixture.
  • ANEDM Construction Bentonite increases the rate of fine-grained alluvium population when mixed with cement grout. Thus, cement failure is prevented. ANEDM Bentonite mixtures behave like a fluid, when mixing is stopped, a homogeneous hardening occurs and high strengths are gained. It is resistant to chemical effects and groundwater.
  • ANEDM Construction Bentonite increases the strength of the mixture when slurry with ANEDM bentonite at a rate of 6%  is injected to green sand.
  • ANEDM Bentonite mixtures are not affected by sulfate salts. If salt and lime are found in abundant amounts in underground waters, good results are obtained when used with phosphate or silicates.
  • when sodium silicate is added at 5% to slurry with ANEDM Bentonite, gelation starts quickly  after injection.
  • The use of clay-cement slurry for filling large cavities increases the ability of the syrup to penetrate and suspend if natural ANEDM Bentonite is added in small quantities.
  • ANEDM Construction Bentonite cement-water mixtures can also be used for injection of alluvium with a permeability less than 10-1 cm / sec as using chemical additives.
  • ANEDM Construction Bentonite acts as a lubricant in works such as submerging dubs, sliding curtains and foundation piles, and reducing friction.
  • ANEDM Construction Bentonite is mixed with water at 1/1 ratio to cover the cracks formed in the walls to prevent water leakage, as being trowelled and tarred.
  • ANEDM Construction Bentonite can be used to fill cracks by being mixed with an organic  waste such as sand kerosene. When the gaseous mixture comes into contact with water, it converts water into a thick and strong gel.
  • A mixture containing 5% ANEDM Construction Bentonite is pumped into the crack with a special injection pump as a solution to invisible cracks.

Note: Please call our technical department for our project-specific bentonite products with different marsh funnel, viscosity, PH, filtrate bulk, sludge density and filter cake values.

Compliance :

  • API 13 A Section 9
  • API 13 A Section 10

Packaging:

  • 50-kg kraft paper bag (with pallet and without pallet)
  • 1000-1200-kg Bags
  • Bulk trailer

Delivery:

  • Ex Dammam

Important Note: Please obtain technical information from our R & D laboratory according to the product characteristic you produce.
